Kinetics of oxidation of sulfur compounds: Rapid oxidation in new design of oscillatory baffled reactor

Authors

  • ِِAmer T. Nawaf Petroleum and Gas Refinery Engineering Department, College of Petroleum Process Engineering, Tikrit University, Iraq / Chemical Engineering Department, College of Engineering, University of Baghdad, Iraq
  • Basma A. Abdul Majeed Chemical Engineering Department, College of Engineering, University of Baghdad, Iraq https://orcid.org/0000-0002-2610-7872
  • Rajesh Haldhar School of Chemical Engineering, Yeungnam University, Gyeongsan 35841, Republic of Korea

DOI:

https://doi.org/10.31699/IJCPE.2025.2.4

Keywords:

Kinetics model; Oxidation reaction; Sulfur removal, Nanocatalyst; Oscillatory baffled reactor

Abstract

   Recently, one of the most crucial objectives for the petroleum refining industries is producing clean or eco-friendly fuel. The world demands clean diesel utilizing simple processes under safe conditions (i.e., moderate operating conditions). For this purpose, an oscillatory helical baffled reactor (OHBR) was designed to improve the oxidative desulfurization (ODS) process, which is achieved here by converting sulfur compounds found in diesel fuel using a new homemade nanocatalyst. First, the homemade catalyst support, γ-alumina nanoparticles, was prepared using precipitation technology. The γ-Al2O3 was then used to design the synthetic nanocatalyst made of iron oxide using the IWI technology with 5% Fe2O3. A good distribution of the metal oxides has maintained a good surface area (SA) and pore volume (PV), resulting in high activity. The ODS of sulfur compounds and the performance of the modified nano-catalyst at different safe reaction conditions (frequency of oscillation from 0-2 Hz, amplitude of oscillation from 2-8 mm, reaction temperature from 50-80 oC and residence time only 9 min) were evaluated in the new designed OHBR. The best removal of sulfur was 73.23% at an oscillation frequency of 2 Hz, oscillation amplitude of 8 mm, and oxidation reaction of 80 oC with a residence time of 9 min under constant pressure. A kinetic model related to the sulfur oxidation from real diesel fuel by the ODS process in the OHBR was also investigated in this manuscript to estimate the best kinetic parameters of the relevant reactions in the first order.

References

[1] M. F. Ali, A. Al-Malki, B. El-Ali, G. Martinie, M. N. Siddiqui, “Deep desulphurization of gasoline and diesel fuels using non-hydrogen consuming techniques” Fuel, Vol. 85, no. (10– 11), pp. 1354–1363, 2006, https://doi.org/10.1016/j.fuel.2005.12.006

[2] G. H. Abdulla, Y. Xing, “Oxidation of Dibenzothiophene in Diesel with In Situ Produced Hydrogen Peroxide” Energy & Fuels, Vol. 32, no. 32, pp. 8254–8258, 2018, https://doi.org/10.1021/acs.energyfuels.8b01630

[3] A. Demirbas, H. Alidrisi, M. A. Balubaid, API Gravity, “Sulfur Content, and Desulfurization of Crude Oil” Petroleum Science and Technology, Vol. 33, pp. 93-101, 2014, https://doi.org/10.1080/10916466.2014.950383

[4] C. Song, X. Ma “New design approaches to ultra-clean diesel fuels by deep desulfurization and deep dearomatization” Applied Catalysis B: Environmental, Vol. 41, no. 10, pp. 207–238, 2003, https://doi.org/10.1016/S0926-3373(02)00212-6

[5] C. Song “An overview of new approaches to deep desulfurization for ultra-clean gasoline, diesel fuel and jet fuel” Catalysis Today, Vol. 86, pp. 211–263, 2003, https://doi.org/10.1016/S0920-5861(03)00412-7

[6] I. V. Babich, J. A. Moulijn “Science and technology of novel processes for deep desulfurization of oil refinery streams: a review” Fuel, Vol. 82, no. 6, pp. 607–631, 2003, https://doi.org/10.1016/S0016-2361(02)00324-1

[7] R. N. Colvile, E. J. Hutchinson, J. S. Mindell, R. F. Warren “The transport sector as a source of air pollution” Atmospheric Environment, vol. 35, no. 9, pp. 1537–1565, 2001, https://doi.org/10.1016/S1352-2310(00)00551-3

[8] A. Stanislaus, A. Marafi, M. S. Rana “Recent advances in the science and technology of ultra low sulfur diesel (ULSD) production” Catalysis Today, vol. 153, no. (1-2), 2, pp. 1–68, 2010, https://doi.org/10.1016/j.cattod.2010.05.011

[9] A. Ishihara, F. Dumeignil, J. Lee, K. Mitsuhashi, E.W. Qian, T. Kabe “Hydrodesulfurization of sulfur-containing polyaromatic compounds in light gas oil using noble metal catalysts” Applied Catalysis A: General, Vol 289, no 2, pp. 163-173, 2005, https://doi.org/10.1016/j.apcata.2005.04.056

[10] A. T. Nawaf, B. A. Abdulmajeed, “Design of oscillatory helical baffled reactor and dual functional mesoporous catalyst for oxidative desulfurization of real diesel fuel” Chemical Engineering Research and Design, Vol. 209, pp. 193-209, 2024, https://doi.org/10.1016/j.cherd.2024.07.032

[11] S. Otsuki, T. Nonaka, N. Takhashima, W. Quian, A. Ishihara, T. Imai, T. Kabe, “Oxidative desulphurization of light gas oil and vacuum gas oil by oxidation and solvent extraction” Energy and Fuels, Vol.14, no. 6, pp.1232-1239, 2000, https://doi.org/10.1021/ef000096i

[12] Parida, K. M., A. C. Pradhan, J. Das, N. Sahu, “Synthesis and characterization of nano-sized porous gamma-alumina by control precipitation method” Materials Chemistry and Physics, Vol.113, pp. 244–248, 2009, https://doi.org/10.1016/j.matchemphys.2008.07.076

[13] A.T. Nawaf, B.A. A. Abdulmajeed, “synthesis of a Fe2O3-supported composite for rapid oxidative desulfurization production of environmentally friendly fuel in an OBR” International Journal of Environmental Science and Technology, 2024, https://doi.org/10.1007/s13762-024-05920-1

[14] Y.-L. Lee, A. Mnoyan, H.-S. Na, S.-Y. Ahn, K.-J. Kim, J.-O. Shim, K. Lee and H.-S. Roh, “Comparison of the effects of the catalyst preparation method and CeO2 morphology on the catalytic activity of Pt/CeO2 catalysts for the water-gas shift reaction” Catalysis Science & Technology, Vol. 10, pp. 6299-6308, 2020, https://doi.org/10.1039/D0CY01067G

[15] Z. Gholizadeh, M. Aliannezhadi, M. Ghominejad, F. S. Tehrani “High specifc surface area γ-Al2O3 nanoparticles synthesized by facile and low-cost co-precipitation method” Scientifc Reports, vol. 13, pp. 6131, 2023, https://doi.org/10.1038/s41598-023-33266-0

[16] J. I. Hammade, S. A. Gheni, S.M. R. Ahmed, A.G. Abdullah, A. Phan, A. Harvey, “Fast, Non-Extractive, and Ultradeep Desulfurization of Diesel in an Oscillatory Baffled Reactor” Process Safety and Environmental Protection, Vol. 152, pp.178-187, 2021, https://doi.org/10.1016/j.psep.2021.05.028

[17] S. S. Ahmed, O. Amiri, K. M. Rahman, S. J. Ismael, N. S. Rasul, D. Mohammad, K. A. Babakr, N A. Abdulrahman, “Studying the mechanism and kinetics of fuel desulfurization using CexOy/NiOx piezo-catalysts as a new low-temperature method,” Scientific Reports, Vol. 13, pp. 7574, 2023, https://doi.org/10.1038/s41598-023-34329-y

[18] A.T. Nawaf, H.H. Hamed, S.A. Hameed, A.T. Jarullah, L.T. Abdulateef, , I.M. Mujtaba, “Performance Enhancement of Adsorption Desulfurization Process Via Different New Nanocatalysts Using Digital Baffle Batch Reactor and Mathematical Modeling” Chemical Engineering Science, Vol. 232, pp. 116384, 2021, https://doi.org/10.1016/j.ces.2020.116384

[19] A.T. Nawaf, S.A. Gheni, A.T. Jarullah, I.M. Mujtaba, “Optimal design of a trickle bed reactor for light fuel oxidative desulfurization based on experiments and modeling” Energy Fuels, Vol. 29, no. 5, pp. 3366–3376, 2015, https://doi.org/10.1021/acs.energyfuels.5b00157

[20] A.T. Nawaf, S.A. Hameed, L.T. Abdulateef, A.T. Jarullah, M.S. Kadhim, I.M. Mujtaba, “A novel synthetic nanocatalyst (Ag2O3/Zeolite) for high quality of light naphtha by batch oxidative desulfurization reactor” Bulletin of Chemical Reaction Engineering & Catalysis, Vol.16, no. 4, pp. 716-732, 2021, https://doi.org/10.9767/bcrec.16.4.11383.716-732

[21] A.T. Jarullah, S. K. Muhammed, B. A. Al-Tabbakh, I. M. Mujtaba, “Design of an environmentally friendly fuel based on a synthetic composite nano-catalyst through parameter estimation and process modeling” Chemical Product and Process Modeling, Vol. 17, pp. 3-18, 2021, https://doi.org/10.1515/cppm-2020-0097

[22] J.I. Humadi, A.T. Nawaf , A.T. Jarullah, M.A. Ahmed, S.A. Hameed, I. M. Mujtaba, Design of new nano-catalysts and digital basket reactor for oxidative desulfurization of fuel: Experiments and modelling” Chemical Engineering Research and Design, Vol. 190, pp.634-650, 2023, https://doi.org/10.1016/j.cherd.2022.12.043

[23] A. T. Jarullah, G. S. Ahmed, B. A. Al-Tabbakh, I. M. Mujtaba, “Enhancement of light naphtha quality and environment using new synthetic nano-catalyst for oxidative desulfurization: Experiments and process modeling” Computers & Chemical Engineering, Vol. 140, no.2, pp. 106869, 2020, https://doi.org/10.1016/j.compchemeng.2020.106869

[24] A. T. Nawaf, A. T. Jarullah, L. T. Abdulateef, “Design of a synthetic zinc oxide catalyst over nano- γ -alumina for sulfur removal by air in a batch reactor” Bulletin of Chemical Reaction Engineering & Catalysis, vol.14, pp.79–9, 2019, https://doi.org/10.9767/bcrec.14.1.2507.79-92

[25] Y. Shi, M. Fan, “Reaction Kinetics for the Catalytic Oxidation of Sulfur Dioxide with Microscale and Nanoscale Iron Oxides” Industrial & Engineering Chemistry Research, 46, no. 1, pp. 80-86, 2007, https://doi.org/10.1021/ie060889d

Downloads

Published

2025-06-30

How to Cite

T. Nawaf ِ., Abdul Majeed, B. A., & Haldhar, R. (2025). Kinetics of oxidation of sulfur compounds: Rapid oxidation in new design of oscillatory baffled reactor. Iraqi Journal of Chemical and Petroleum Engineering, 26(2), 35-45. https://doi.org/10.31699/IJCPE.2025.2.4
